24" Wide Built-In All-Freezer

SKU: ACF48W

Frost-free operation eliminates the need to defrost the interior

Estimated Time to Ship:

5 to 7 days

How to Buy

Add a naturally antimicrobial copper handle for added protection against germs and bacteria.

33.5" H x 23.63" W x 21.63" D
(85cm H x 60cm W x 55cm D)

Overview
Nominal Height	33.0" (84 cm)
Height of Cabinet	33.0" (84 cm)
Height to Hinge Cap	33.5" (85 cm)
Nominal Width	24.0" (61 cm)
Width	23.63" (60 cm)
Nominal Depth	22.0" (56 cm)
Depth	21.63" (55 cm)
Depth with Handle	23.5" (60 cm)
Depth with door at 90°	44.25" (112 cm)
Capacity	3.1 cu.ft. (88 L)
Defrost Type	Frost-Free
Door	White
Cabinet	White
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Sanitation	ETL-S
Amps	1.5
Weight	100.0 lbs. (45 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101051345
Freezer
Door Swing	RHD
Reversible	Yes
Height Adjustable	33" to 34.5"
Interior Height	24.5" (62 cm)
Interior Width	17.5" (44 cm)
Interior Depth	14.5" (37 cm)
Shelf Type	Steel
Shelf Qty	2
Thermostat Type	Digital
Fan Type	Interior and Exterior
Refrigerant Type	R134a
Refrigerant Amount	4.2 oz.
High Side PSI	285.0
Low Side PSI	70.0
Level Legs	4
Compressor Step Height	6.0" (15 cm)
Compressor Step Width	17.5" (44 cm)
Compressor Step Depth	3.0" (8 cm)
Temperature Range	-5 to 10ºF/-20 to -12ºC

Exterior

SSK - Stainless steel kickplate Stainless steel kickplate factory installed	LHD - Left hand door swing Door reversal to left hand swing
SCD - Self-closing door Protect interior contents and reduce energy waste with the Self Closing Door Option	PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices
Alarm/Thermometer - Factory-installed alarm with external temperature readout Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations	Latch - Factory-installed door latch requires manual release to open unit Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles (NOTE: latch adds 1 1/2" of width to unit)
DL2B - Factory installed NIST calibrated digital data logger (DDL) USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout

Lock

AC Keypad - AC powered keypad lock

KEYPAD - Battery-powered keypad door lock

Handle

TBC Copper Towel Bar Handle

CP Full-Length Copper Pipe Handle

Door

STO-Step-To-Open Door Pedal

Slim undercounter dimensions

Sized at less than 24" wide and deep for an easy fit in space-challenged institutions

Built-in capable

Make the best use of space by installing your appliance under the counter and flush with other cabinets

Frost-free operation

Low maintenance design ensures no frost buildup inside the unit

Digital temperature control

Electronic controls located in the exterior kickplate for precise temperature management

Internal fan

Fan-forced cooling ensures the unit is evenly cooled from top to bottom

Factory installed lock

Keyed lock for added security, located towards the top of the door to ensure convenient access

Removable shelves

Includes two slide-out shelves made from durable steel

One piece interior liner

Enjoy easy clean-up with a seamless liner that won't hold a mess in hidden crevices

Reversible door

User-reversible door swing for added flexibility

Hospital grade cord

Secure three-pronged cord for added unit safety

Flat door liner

Interior design conforms to CDC guidelines to ensure stable conditions for sensitive materials

Fully finished white cabinet

Allows the unit to be used freestanding

Matching refrigerator available

Pair with the FF7LBI to create a matching set

Foamed-in-place cabinet

Quality design ensures efficiently insulated interior

Commercially approved

Design meets UL-471 and is ETL-S listed to NSF-7 commercial standards

100% CFC free

Environmentally friendly design without ozone-damaging chemicals

Accucold by Summit Appliance carries a range of general purpose and medical all-freezers designed for reliable, frost-free storage under the counter.

At 24" wide, the ACF48W is ideally sized for various institutional or laboratory settings. The front-breathing design allows built-in installation, while the fully finished cabinet also allows freestanding use. The user-reversible door includes a factory installed keyed lock for added security. This model comes in a white finish and includes a hospital grade cord with a 'green dot' plug for added security in high traffic areas.

Full frost-free operation ensures low maintenance operation, with an internal fan to keep the interior evenly cooled from top to bottom. A digital thermostat is located in the front kickplate, letting users manage the temperature without having to open the door. The interior includes two removable steel shelves.

Made in the USA, the ACF48W offers quality freezer storage in a conveniently sized and featured unit. It is ETL-S listed to NSF-7 commercial standards and meets UL-471. For this unit sized for use under ADA compliant counters, see the ACF48WADA. Additional door finishes are available. This model can also be paired with the matching FF7LWBI all-refrigerator.

Note: This product is intended for a wide variety of basic storage applications. Storage of high-value vaccines, life science materials, and medical/clinical biologicals require a product offering tighter temperature control and/or alarms, monitoring, and backup. For more information, browse Accucold's purpose-built line or contact our product specialists at 1-888-4-MED-LAB.

BROCHURE
ACF48W.pdf

TECHNICAL DRAWING (.dwg)
ACF48W_FREEZER__A-C_2000_.dwg

USE & CARE
ACF48W_SCUF48W_series_manual_rvsd_031516.pdf

This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or info@accucold.com

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
