28" Wide Pharmacy Refrigerator

SKU: ACR1718LH
Stainless steel interior for improved sanitation and durable storage in busy settings
Estimated Time to Ship:

Next day shipping

79.75" H x 27.63" W x 24.75" D
(203cm H x 70cm W x 63cm D)

Overview
Nominal Height 80.0" (203 cm)
Height of Cabinet 79.25" (201 cm)
Height to Hinge Cap 79.75" (203 cm)
Nominal Width 28.0" (71 cm)
Width 27.63" (70 cm)
Nominal Depth 25.0" (64 cm)
Depth 24.75" (63 cm)
Depth with Handle 26.75" (68 cm)
Depth with door at 90° 51.0" (130 cm)
Capacity 17.0 cu.ft. (481 L)
Defrost Type Automatic
Door Glass
Cabinet Stainless Steel
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Amps 3.4
Voltage/Frequency 115 V AC/60 Hz
Weight 210.0 lbs. (95 kg)
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101053639
Refrigerator Features
Door Swing LHD
Reversible No
Shelf Type Plastic
Shelf Qty 6
Adjustable Shelves Yes
Thermostat Type Digital
Fan Type Interior
Refrigerant Type R290
Refrigerant Amount 2.33oz.
Condensor Location Rear of Unit
Interior Light Yes
Temperature Range 2° to 8°C
Sound Level 50.2 dB
Dimensions
Interior Height 55.0" (140 cm)
Interior Width 25.0" (64 cm)
Interior Depth 19.25" (49 cm)

Exterior
TM1A - Factory-installed dry contacts with remote alarm
Remote alarm contacts with continuous temperature display
PH - Probe Hole
Factory installed probe hole for customer supplied monitoring devices
DL2B - Factory installed NIST calibrated digital data logger (DDL)
USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
Interior
LockBox17 - Interior locking compartment
Interior drop-down compartment with combination lock for use in ACR1717

Large capacity

17 cu.ft. interior for maximum storage convenience

LED lighting

Individual lights in door pane offer a full view of stored contents, with an off switch located inside

Automatic defrost

Reduced user maintenance with automatic defrost

Stainless steel interior and exterior finish

Cabinet and interior walls are constructed from stainless steel

Glass door

Tempered glass door provides heat-safe view of interior contents

Factory installed lock

Keyed lock for a secure interior

Adjustable cantilevered shelves

6 molded plastic shelves can be arranged in virtually any position to accommodate a variety of sizes

Self-closing door

Door automatically closes if left ajar

Fan-cooled interior

Interior fan-forced cooling ensures all items are kept cold

Danfoss compressor

1/4 horsepower high efficiency compressor for quality storage

Operates between 2º and 8ºC

Designed to maintain temperatures as recommended by the CDC

Optional drawers

ACR17 Drawer option available for easy installation inside the unit. Full-extension drawers are constructed from aluminum

Left hand door swing

Door is not field reversible. For a right hand swing, order ACR1718RH

100% CFC free

Environmentally friendly design with no ozone-damaging chemicals

CARB Compliant

Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

Accucold by Summit Appliance carries a quality line of pharmaceutical refrigeration for temperature-safe storage of sensitive material.

The ACR1718LH offers 17 cu.ft. of interior storage, with six adjustable cantilevered shelves to accommodate a variety of sizes. The shelves are constructed from heavy duty recycled molded plastic for lasting durability. As an alternative, we offer a separate full-extension drawer in a durable aluminum finish that can be ordered with this unit. Fan-forced cooling ensures cold air is evenly distributed throughout the stainless steel interior. This model uses automatic defrost operation for easy user maintenance, with audible high/low temperature alarms to warn if the unit goes out of range.  A digital thermostat offers intuitive and reliable temperature control. Designed for optimum pharmaceutical storage, the temperature range is 2ºC to 8ºC.

The ACR1718LH comes with a stainless steel cabinet with a locking tempered self-closing glass door, an ideal time-saving feature for busy staffs that helps to ensure items aren’t accidentally exposed to room temperature. LED lighting in the door panel allows all stored items to be fully displayed. A hidden light switch is conveniently located towards the top of the unit, letting staff turn the lights off during off hours. This unit features a high efficiency compressor and maintenance-free rear condenser.  A factory installed keyed lock offers added security in preventing unsupervised access to sensitive materials.

NOTE: This unit has a left hand door swing. For a right hand door swing, see the ACR1718RH.

NOTE: Accucold refrigerators are purpose-built to the support meeting the current CDC (Centers for Disease Control) guidelines for the storage of vaccines. At this time, Accucold refrigerators have not been evaluated to the new NSF 456 standard. As referenced in the current Vaccine Storage and Handling Toolkit, these units incorporate microprocessor controls and forced air circulation for stable operation between 2 and 8ºC. For additional temperature assurance, the CDC recommends a calibrated digital data logger (DDL), which can be added with the factory-installed option DL2B or addition of the DL2BKit accessory.

Download
BROCHURE w/ DRAWINGS
ACR1718LH.pdf
Download
TECHNICAL DRAWING (.dwg)
ACR1718LH_PHARMA.__A-C_2018__REF..dwg
Download
ASSEMBLY DRAWING
ACR1718LH_ASS_Y.pdf

This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or info@accucold.com

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
