12" Wide 230V 2-Burner Coil Cooktop
Next day shipping
(8cm H x 30cm W x 50cm D)
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Nominal Height | 3.25" (8 cm) |
| Height of Cabinet | 3.25" (8 cm) |
| Nominal Width | 12.0" (30 cm) |
| Width | 12.0" (30 cm) |
| Nominal Depth | 20.0" (51 cm) |
| Depth | 19.75" (50 cm) |
| Cabinet | Black |
| US Electrical Safety | ETL |
| Canadian Electrical Safety | ETL-C |
| Amps | 7.0 |
| Voltage/Frequency | 230 V AC/60 Hz |
| Weight | 14.0 lbs. (6 kg) |
| Parts & Labor Warranty | 1 Year |
| UPC | 761101060811 |
|
Electric Cooktop
|
|
| Surface | Porcelain |
| Element Type | Coils |
| Number of Elements | 2 |
| Controls | Dial |
| Countertop Cutout Height | 5.0" (13 cm) |
| Countertop Cutout Width | 11.13" (28 cm) |
| Countertop Cutout Depth | 19.13" (49 cm) |
| Power Source | 230V |
| Element #1 Size | 6.0" (15 cm) |
| Element #1 Wattage | 675.0 |
| Element #2 Size | 8.0" (20 cm) |
| Element #2 Wattage | 950.0 |
| Power Cord Included | No |
FEATURES
Designed and constructed domestically
Designed for 11 1/8" W x 19 1/8" D cutouts for an easy fit in smaller kitchens
Jet black exterior for an easy complement to any kitchen space
Scratch-resistant design for lasting durability
Curved design helps to contain spills on the surface
Traditional design offers reliable heating and strong durability for everyday cooking
Larger element is ideal for heating wider pots and pans
Standard burner accommodates most heating needs
Complies with the latest UL safety standards, the elements operate at lower wattage for slower but steadier heating that will not cycle off
Removable drip pans for easier cleanup
Knobs require a small amount of force for added safety
Upfront lights illuminate to show which burners are in use
Upfront controls and easy-to-operate knobs offer easier accessibility that complies with the Americans for Disabilities Act (ADA) guidelines
Requires a 15 amp circuit
Designed for hard-wired installation (cord not included)
DESCRIPTION
Summit offers an extensive selection of slim-fitting cooktops designed and manufactured in the USA. The CCE226BL is a 220-240V cooktop with a porcelain surface in a jet black finish. Two coil elements (6" 675W in front and 8" 950W in rear) offer durable heating that holds up to everyday use. Designed to meet the most recent UL safety standards, the elements operate at low wattage, allowing for a slow but steady heating process that will not cycle off. Each element includes a removable chrome drip pan for easier cleanup. Upfront push-to-turn knobs are simple and intuitive, with indicator lights that show which burner is in use for added safety. The recessed design helps to contain spills for a cleaner cooking experience. This cooktop is designed to fit common 11 1/8" W x 19 1/8" D counter cutouts. This unit does not ship with a power cord and must be hard-wired by a professional. Additional choices are available in 115V, as well as white and stainless steel. Browse our website for our complete selection of slim-fitting cooking appliances.
Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
California residents:
WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
