24" Wide Built-In All-Refrigerator, ADA Compliant
3 to 5 days
(82cm H x 60cm W x 60cm D)
SPECIFICATIONS
|
Overview
|
|
|---|---|
| Nominal Height | 32.0" (81 cm) |
| Height of Cabinet | 32.0" (81 cm) |
| Height to Hinge Cap | 32.25" (82 cm) |
| Nominal Width | 24.0" (61 cm) |
| Width | 23.63" (60 cm) |
| Nominal Depth | 24.0" (61 cm) |
| Depth | 23.5" (60 cm) |
| Depth with Handle | 24.0" (61 cm) |
| Depth with door at 90° | 45.13" (115 cm) |
| Capacity | 5.5 cu.ft. (156 L) |
| Defrost Type | Automatic |
| Door | White |
| Cabinet | White |
| US Electrical Safety | UL |
| Canadian Electrical Safety | ULC |
| Sanitation | ETL-S |
| Amps | 1.4 |
| Voltage/Frequency | 115 V AC/60 Hz |
| Weight | 100.0 lbs. (45 kg) |
| Parts & Labor Warranty | 1 Year |
| Compressor Warranty | 5 Years |
| UPC | 761101068121 |
|
Refrigerator Features
|
|
| Door Swing | RHD |
| Reversible | Yes |
| Shelf Type | Wire |
| Shelf Qty | 3 |
| Adjustable Shelves | Yes |
| Thermostat Type | Digital |
| Fan Type | Interior |
| Refrigerant Type | R600a |
| Refrigerant Amount | 0.64oz. |
| High Side PSI | 180.0 |
| Low Side PSI | 80.0 |
| Level Legs Qty | 4 |
| Interior Light | Yes |
| Temperature Range | 1 to 10°C |
|
Dimensions
|
|
| Interior Height | 26.25" (67 cm) |
| Interior Width | 21.0" (53 cm) |
| Interior Depth | 17.75" (45 cm) |
| Compressor Step Height | 5.5" (14 cm) |
| Compressor Step Width | 21.0" (53 cm) |
| Compressor Step Depth | 5.5" (14 cm) |
AVAILABLE UPGRADES
| Exterior | ||
|---|---|---|
|
||
| Handle | ||
|
||
| Door | ||
|
FEATURES
Designed for general purpose storage in institutional facilities
32 inch height fits under standard ADA counters
ETL-S listed to NSF-7 Standards for use in commercial establishments
Less than 24 inches wide with a full 5.5 c.f. capacity
Make the best use of space by installing your appliance under the counter and flush with other cabinets
Internal fan ensures the interior is evenly cooled from top to bottom
Allows the unit to be used freestanding
Keyed lock for a secure interior
User-reversible door swing for added flexibility
Reduced user maintenance with automatic defrost
Digital thermostat for easy monitoring of interior temperature
Enjoy easy clean-up with a seamless liner that won't hold a mess in hidden crevices
Cold wall design with hidden evaporator and seamless interior
Rearrange the refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up
Interior accommodates large trays up to 19 1/2" x 15 1/2"
Turn the light on when you need it and off when you're done with a convenient rocker switch
Environmentally friendly design without ozone-damaging chemicals
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
DESCRIPTION
Accucold's series of general purpose refrigeration includes a variety of choices ideal for use in healthcare applications. The FF7LWBIADAGP is an ADA compliant, built-in all-refrigerator designed to offer an improved performance over similarly sized dorm fridges and residential units. Sized at 32" high, with a full 5.5 cu. ft. capacity inside a slim 24" footprint. The front-breathing design allows built-in use under counters, while the fully finished cabinet also lets this unit be used freestanding. This model has a white exterior and user-reversible door swing. A factory installed front lock offers added security. Inside, the FFL7WBIADAGP utilizes low maintenance automatic defrost operation. Our unique "hidden" evaporator is set behind the rear wall to create a seamless, easy-to-clean interior that also maximizes shelf space. This unit has a flat door liner that allows it to accept larger trays (up to 19 1/2" x 16"). Adjustable wire shelves allow users to reconfigure the interior to accommodate a variety of sizes. The interior light is controlled by an on/off rocker switch. An internal fan ensures proper cold air circulation throughout the unit, while the digital thermostat allows for an easy temperature management. The FF7LWBIADAGP is ETL-S listed to NSF-7 standards for use in commercial establishments. It is a convenient solution to general purpose cold storage applications. Additional general purpose choices are available as freezers and in undercounter, ADA compliant, and large capacity sizes. NOTE: This unit is designed for general purpose or commercial applications and does not meet DOE energy standards for residential use. Note: Accucold's general purpose series refrigerators are intended for a wide variety of basic storage of non-critical products. For storage of high-value vaccines, life science materials, and medical or clinical biologicals, browse Accucold's Medical & Laboratory or Pharmacy & Vaccine Storage categories, or contact our product specialists to discuss your options at 1-888-4-MED-LAB.
This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or info@accucold.com
Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
California residents:
WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
