24" Wide All-Refrigerator/All-Freezer Combination

SKU: FFAR10-FS30LSTACKPRO
Stackable design allows you to maximize limited floor space while enjoying the full storage convenience of an independent refrigerator and freezer
DISCONTINUED- REPLACED BY ARS8PV-AFZ1PVSTACK
80.0" H x 23.63" W x 23.5" D
(203cm H x 60cm W x 60cm D)

Overview
Nominal Height 80.0" (203 cm)
Height of Cabinet 80.0" (203 cm)
Nominal Width 24.0" (61 cm)
Width 23.63" (60 cm)
Nominal Depth 24.0" (61 cm)
Depth 23.5" (60 cm)
Depth with door at 90° 45.5" (116 cm)
Capacity 12.1 cu.ft. (343 L)
Door White
Cabinet White
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Voltage/Frequency 115 V AC/60 Hz
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
UPC 761101058863
Refrigerator-Freezer
Door Swing RHD
Reversible Factory Reversible
Adjustable Shelves Yes
Interior Light Yes
Refrigerator - Interior Height 48.0" (122 cm)
Refrigerator - Interior Width 21.0" (53 cm)
Refrigerator - Interior Depth 17.75" (45 cm)
Refrigerator - Capacity 10.1 cu.ft
Refrigerator - Shelf Type Wire
Refrigerator - Shelf Qty 4
Refrigerator - Temperature Range 2 to 8ºC / 36 to 46ºF
Refrigerator - Refrigerant Type R134a
Refrigerator - Refrigerant Amount 3.0 oz.
Freezer - Interior Height 18.63" (47 cm)
Freezer - Interior Width 13.38" (34 cm)
Freezer - Interior Depth 13.0" (33 cm)
Freezer - Capacity 1.8 cu.ft
Freezer - Shelf Type Wire
Freezer - Shelf Qty 2
Thermostat Type Digital + Dial
Fan Type Interior
Freezer - Temperature Range -20º to -15ºC
Freezer - Refrigerant Type R600a
Freezer - Refrigerant Amount 0.8 oz.

Exterior
TM1A - Factory-installed dry contacts with remote alarm
Remote alarm contacts with continuous temperature display
Latch - Factory-installed door latch requires manual release to open unit
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD - Left hand door swing
Door reversal to left hand swing
Alarm/Thermometer - Factory-installed alarm with external temperature readout
Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
HG - Hospital grade cord
Add a hospital grade cord equipped with green dot plug with the HG suffix
DTMEDF - Digital thermostat with Fahrenheit readout
Change thermostat to read in Fahrenheit (no charge)
CAS3 3" casters
3" high NSF listed casters designed for institutional use, made from non-marring hard rubber in gray finish
DL2B - Factory installed NIST calibrated digital data logger (DDL)
USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
Lock
KEYPAD - Battery-powered keypad door lock
Battery-powered keypad door lock installed for keyless security
AC Keypad - AC powered keypad lock
Keypad door lock powered by appliance power cord for keyless security
Interior
LockBox24 - Interior locking compartment
Interior lift-up compartment with combination lock for use in FF7 and FFAR10 models
Handle
TBC Copper Towel Bar Handles
Factory-installed towel bar handles made from pure copper for antimicrobial protection
CP Full-Length Copper Pipe Handles
Factory-installed full-length handles made from pure copper for antimicrobial protection

Space-saving design

Allows you to create a full refrigerator-freezer with independent controls in a slim-fitting footprint

FFAR10PRO all-refrigerator

10.1 cu.ft. auto defrost all-refrigerator with digital controls, internal fan, flat door liner, and adjustable shelving

FS30LPRO freezer

Compact manual defrost all-freezer with factory-installed probe hole

Factory installed locks

Both models include locks (front-mounted on the freezer, side-mounted on the refrigerator) for added security, with two keys included for each unit

Access ports

Refrigerator and freezer include a 3/8" factory-installed probe hole to allow users to connect their own monitoring equipment

Hospital grade cords with 'green dot' plugs

Secure three-pronged cord for added unit safety (both units)

Flat door liner

No door shelving to offer more storage depth and better temperature stability

Easy assembly

Unit ships in three boxes for customer to install the StackRack on the bottom refrigerator/freezer and place and secure the other unit on top

Anti-tip bracket included

StackRack ships with anti-tip bracket for easy aftermarket installation

Foamed-in-place cabinets

Designed to ensure a sufficiently insulated interior

Magnetic door gaskets

Quality door gaskets ensure a tight seal for energy savings and improved performance

Approved for use in the USA and Canada

ETL and ETL-C listed for North American sales

100% CFC free

Environmentally friendly design with no ozone-damaging chemicals

Accucold's stackable PRO series refrigerator-freezer combinations offer space-saving cooling solutions for general purpose use.

Sized at just 24" wide, the FFAR10-FS30LSTACKPRO combines two slim-fitting units into one compact footprint. All-refrigerator FFAR10PRO is made in Europe and features a 10.1 cu.ft. auto defrost interior with adjustable wire shelves and a flat door liner. The digital thermostat provides easy temperature management, with an internal fan to ensure even cooling from top to bottom. Compact FS30LPRO all-freezer utilizes a static manual defrost cooling system. It includes two adjustable wire shelves, flat door liner, and dial thermostat.

Both models include locks for added security, with two keys included for each unit. Hospital grade cords with 'green dot' plugs offer added convenience for busy facilities, ensuring the cords are not easily dislodged from the wall socket. Factory-installed probe holes are included on both units to allow users to install their own monitoring devices.

All Accucold STACKPRO units ship in three boxes and require some minor assembly upon delivery. Additional stacked combinations can be created by ordering virtually any two units with our StackRack. These units can also be customized with a variety of refrigeration options, including NIST calibrated thermometers, USB data loggers, open door alarms, and much more. To create a custom combination, contact our sales team at 718-893-3900.

*NOTE: The refrigerator's thermostat is pre-set for Celsius. If you prefer Fahrenheit, add complimentary option DTMEDF or let your sales representative know upon order.

This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or info@accucold.com

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
