Compact All-Freezer

SKU: FS24LVAC
Specially designed to store vaccines with more temperature stability
Estimated Time to Ship:

5 to 7 days

Add a naturally antimicrobial copper handle for added protection against germs and bacteria.
21.38" H x 18.5" W x 17.63" D
(54cm H x 47cm W x 45cm D)

Overview
Nominal Height 22.0" (56 cm)
Height of Cabinet 21.38" (54 cm)
Nominal Width 19.0" (48 cm)
Width 18.5" (47 cm)
Nominal Depth 18.0" (46 cm)
Depth 17.63" (45 cm)
Depth with door at 90° 34.5" (88 cm)
Capacity 1.4 cu.ft. (40 L)
Defrost Type Manual
Door White
Cabinet White
US Electrical Safety ETL
Canadian Electrical Safety ETL-C
Amps 1.0
Voltage/Frequency 115 V AC/60 Hz
Weight 35.0 lbs. (16 kg)
Parts & Labor Warranty 2 Years
Compressor Warranty 5 Years
UPC 761101049236
Freezer
Door Swing RHD
Reversible Factory Reversible
Interior Height 14.38" (37 cm)
Interior Width 13.5" (34 cm)
Interior Depth 13.25" (34 cm)
Shelf Type Wire
Shelf Qty 1
Thermostat Type Digital
Refrigerant Type R600a
Refrigerant Amount 0.8 oz.
High Side PSI 110.0
Low Side PSI 70.0
Level Legs 2
Compressor Step Height 8.5" (22 cm)
Compressor Step Width 13.5" (34 cm)
Compressor Step Depth 6.0" (15 cm)

Exterior
TM1A - Factory-installed dry contacts with remote alarm
Remote alarm contacts with continuous temperature display
FA Front - Fan assist
Fan assisted cooling for enclosed use in cubbies or cabinets, front breathing
FA Rear - Fan assist
Fan assisted cooling for enclosed use in cubbies or cabinets, rear breathing
Latch - Factory-installed door latch requires manual release to open unit
Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
LHD - Left hand door swing
Door reversal to left hand swing
DL2B - Factory installed NIST calibrated digital data logger (DDL)
USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout
Lock
AC Keypad - AC powered keypad lock
Keypad door lock powered by appliance power cord for keyless security
KEYPAD - Battery-powered keypad door lock
Battery-powered keypad door lock installed for keyless security
Handle
TBC Copper Towel Bar Handle
Factory-installed handle made from pure copper for antimicrobial protection
CP Full-Length Copper Pipe Handle
Factory-installed full-length handle made from pure copper for antimicrobial protection

Compact dimensions

Ideal size for use on top of counters

-20° capable

Low temperature capability ideal for certain sensitive items

Digital thermostat

Electronic controls for more precise temperature management

High/low temperature alarm

Audible alarm sounds if the interior temperature rises or falls out of set range

NIST calibrated temperature display

Alarm includes NIST calibrated display of the current interior and high/low temperature to the nearest tenth of a degree

Factory installed lock

Keyed lock for secure interior

Self-closing door

Door closes automatically when opened at angles less than 90º

3/8" access port

Unit comes with a factory installed probe hole for users to connect their own monitoring equipment

Hospital grade cord with 'green dot' plug

Secure three-pronged cord for added unit safety

Manual defrost

Static cooling system for reduced temperature fluctuations

Removable shelf

Includes one wire shelf for easier storage

One-piece interior liner

Seamless interior for easier cleanup

Flat door liner

Interior design conforms to CDC guidelines to ensure stable conditions for sensitive materials

Factory reversible door

Standard unit ships RHD but can be ordered LHD

100% CFC Free

Environmentally friendly design with no ozone-damaging chemicals

CARB Compliant

Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

The Accucold® VAC Series freezers are specially designed to store sensitive medical and pharmaceutical materials under the proper conditions, with innovative construction for temperature stability and user-friendly features for added convenience.

The FS24LVAC is a compact all-freezer designed to reach -20º C, the ideal temperature for long-term storage of select sensitive materials. The 1.4 cu.ft. manual defrost interior offers static cooling for stable results. A removable wire shelf allows easy storage options, with a seamless interior liner to simplify cleanup. This unit has a flat door liner as recommended by the CDC.

For optimum temperature assurance, the FS24LVAC includes a digital thermostat and a high/low temperature alarm with a NIST calibrated temperature display to the nearest tenth of a degree. A hospital grade cord includes a 'green dot' plug for added safety in high traffic settings, while the self-closing door ensures stored items aren't accidentally exposed to room temperature. This model comes in a white finish and includes a factory installed lock. A pre-installed probe hole/access port allows users to install additional monitoring equipment.

NOTE: Accucold freezers are purpose-built to the support meeting the current CDC (Centers for Disease Control) guidelines for the storage of vaccines. As referenced in the current Vaccine Storage and Handling Toolkit, these units incorporate several key features for stable operation. For additional temperature assurance, the CDC recommends a calibrated digital data logger (DDL), which can be added with the factory-installed option DL2B or addition of the DL2BKit accessory. Select Accucold products have been tested and certified to the new NSF 456 standard, and are now available for purchase. For additional information, contact our products specialists.

Download
BROCHURE
FS24LVAC.pdf
Download
MSDS INFORMATION
Propylene_Glycol_SDS.pdf
Download
MSDS INFORMATION
R134a_AO.pdf

This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or info@accucold.com

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.

California residents:

Warning WARNING: This product can expose you to chemicals including nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Note: Nickel is a component of stainless steel.
