Compact All-Freezer

SKU: FS30LMED

Includes a NIST calibrated high/low temperature alarm

Estimated Time to Ship:

3 to 5 days

How to Buy

Add a naturally antimicrobial copper handle for added protection against germs and bacteria.

24.63" H x 18.5" W x 17.75" D
(63cm H x 47cm W x 45cm D)

Overview
Nominal Height	25.0" (64 cm)
Height of Cabinet	24.5" (62 cm)
Height to Hinge Cap	24.63" (63 cm)
Nominal Width	19.0" (48 cm)
Width	18.5" (47 cm)
Nominal Depth	18.0" (46 cm)
Depth	17.75" (45 cm)
Depth with door at 90°	34.5" (88 cm)
Capacity	1.8 cu.ft. (51 L)
Defrost Type	Manual
Door	White
Cabinet	White
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Amps	0.8
Voltage/Frequency	115 V AC/60 Hz
Weight	50.0 lbs. (23 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101041117
Freezer
Door Swing	RHD
Reversible	Factory Reversible
Interior Height	18.63" (47 cm)
Interior Width	13.38" (34 cm)
Interior Depth	13.0" (33 cm)
Shelf Type	Wire
Shelf Qty	2
Thermostat Type	Dial
Refrigerant Type	R600a
Refrigerant Amount	0.8 oz.
Level Legs	2
Compressor Step Height	8.0" (20 cm)
Compressor Step Width	13.38" (34 cm)
Compressor Step Depth	5.75" (15 cm)

Exterior

TM1A - Factory-installed dry contacts with remote alarm Remote alarm contacts with continuous temperature display	DT - Digital thermostat Install a digital thermostat with external readout for precise temperature management
Latch - Factory-installed door latch requires manual release to open unit Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles (NOTE: latch adds 1 1/2" of width to unit)	LHD - Left hand door swing Door reversal to left hand swing
SCD - Self-closing door Protect interior contents and reduce energy waste with the Self Closing Door Option	DL2B - Factory installed NIST calibrated digital data logger (DDL) USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout

Lock

AC Keypad - AC powered keypad lock

KEYPAD - Battery-powered keypad door lock

Handle

TBC Copper Towel Bar Handle

CP Full-Length Copper Pipe Handle

Compact dimensions

Sized for easy use on top of counters

Manual defrost

Static cooling system for improved temperature stability

Temperature alarm

High/low temperature alarm audibly warns when interior is out of set range

NIST calibrated temperature display

Alarm includes NIST calibrated display of the current interior and high/low temperature

Hospital grade cord with 'green dot' plug

Secure three-pronged cord for added unit safety

-20ºC capable

Low temperature capability ideal for certain sensitive items

Factory installed lock

Keyed lock for a secure interior

Adjustable thermostat

Dial thermostat located inside the unit

Removable shelves

Wire shelves can be removed to accommodate different sizes or for easy cleanup

Flat door liner

Interior design conforms to CDC guidelines to ensure stable conditions for sensitive materials

Access port

Unit comes with a factory installed probe hole for users to connect their own monitoring equipment

One piece interior liner

Easy clean-up with a seamless liner that won't hold a mess in hidden crevices

Fully finished cabinet

Allows the unit to be used freestanding

100% CFC free

Environmentally friendly design without ozone-damaging chemicals

CARB Compliant

Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

Accucold by Summit Appliance offers MED series all-freezers with a stabilized temperature performance for use in medical, scientific, pharmaceutical, and laboratory institutions.

The FS30LMED is a compact 1.8 cu.ft. all-freezer designed for countertop use. The door includes a front lock and high temperature warning alarm that also displays the current and high/low temperatures. The interior includes removable wire shelves for optimum circulation and a one-piece interior liner to ensure easy cleanup. The dial thermostat is located inside the unit. This freezer is manual defrost and operates at an average temperature of -20ºC. A hospital grade 'green dot' cord is included.

With reliable construction and a convenient size, the FS30LMED is the ideal freezer for storing select items in institutional facilities.

Note: This product is intended for a wide variety of basic storage applications. Storage of high-value vaccines, life science materials, and medical/clinical biologicals require a product offering tighter temperature control and/or alarms, monitoring, and backup. For more information, browse Accucold's purpose-built line or contact our product specialists at 1-888-4-MED-LAB.

BROCHURE w/ DRAWINGS
FS30LMED.pdf

TECHNICAL DRAWING (.dwg)
FS30L_FREEZERA-C2000.dwg

USE & CARE
MED_PLUS_manual_Engl_French_rvsd_071916.pdf

MSDS INFORMATION
Propylene_Glycol_SDS.pdf

MSDS INFORMATION
R600a_AO.pdf

This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or info@accucold.com

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
