Compact Beverage Center

SKU: SCR314L

Perfectly sized for countertop use, with a user-reversible door swing for added flexibility

Estimated Time to Ship:

Next day shipping

How to Buy

Available with an energy saving door tint to protect the interior from natural and artificial light. Choose from four tint finishes with varying levels of visibility.

All tints reject up to 99% of UV rays. Click here to view these options and learn more about their efficiency.

This product qualifies for next day delivery to select areas within our trucking radius and may be shipped next day after order for nationwide customers.

This unit meets NSF sanitation standards for commercial use. For information on its commercial sanitation listing, see Specifications.

24.75" H x 18.88" W x 17.0" D
(63cm H x 48cm W x 43cm D)

Overview
Nominal Height	25.0" (64 cm)
Height of Cabinet	24.25" (62 cm)
Height to Hinge Cap	24.75" (63 cm)
Nominal Width	19.0" (48 cm)
Width	18.88" (48 cm)
Nominal Depth	17.0" (43 cm)
Depth	17.0" (43 cm)
Depth with Handle	18.38" (47 cm)
Depth with door at 90°	35.0" (89 cm)
Capacity	2.1 cu.ft. (59 L)
Defrost Type	Automatic
Door	Glass
Cabinet	Black
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Sanitation	ETL-S
Amps	1.3
Voltage/Frequency	115 V AC/60 Hz
Weight	53.0 lbs. (24 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101056647
Refrigerator Features
Door Swing	RHD
Reversible	Yes
Shelf Type	Wire
Shelf Qty	2
Adjustable Shelves	Yes
Thermostat Type	Dial
Fan Type	Interior
Refrigerant Type	R600a
Refrigerant Amount	0.71oz.
High Side PSI	320.0
Low Side PSI	120.0
Interior Light	Yes
Temperature Range	34°F to 46°F/1 to 8ºC
Sound Level	33.5 dB
Dimensions
Interior Height	20.75" (53 cm)
Interior Width	15.75" (40 cm)
Interior Depth	12.75" (32 cm)
Compressor Step Height	7.0" (18 cm)
Compressor Step Width	15.75" (40 cm)
Compressor Step Depth	6.0" (15 cm)

Door

T2 Door Tint Tinted door in reflective deep blue finish with high energy savings	T4 Door Tint Neutral door tint in light smoke finish for moderate energy savings
T3 Door Tint Reflective door tint in light blue finish for medium energy savings	T1S Door Tint Reflective door tint in dark smoke finish for maximum energy savings
T1 Door Tint Tinted door in low-E mirror finish for maximum energy savings

Exterior

PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices	Alarm/Thermometer - Factory-installed alarm with external temperature readout Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations
FA Rear - Fan assist Fan assisted cooling for enclosed use in cubbies or cabinets, rear breathing	FA Front - Fan assist Fan assisted cooling for enclosed use in cubbies or cabinets, front breathing
DL2B - Factory installed NIST calibrated digital data logger (DDL) USB digital data logger with internal memory, user-set recording intervals, high/low temperature alarm, and NIST calibrated temperature readout

Commercially approved

ETL-S listed to NSF-7 commercial standards and meets UL-471

Double pane tempered glass door

Heat-safe view for full visibility, with stainless steel trim for an attractive look

User-reversible door swing

Door can be reversed to accommodate any setup

Professional handle

Brushed stainless steel finish suits any setting

Factory installed lock

Keyed lock offers added security (2 keys included)

Automatic defrost

No-frost convenience for reduced user maintenance

Interior LED light

Automatically illuminates when the door is open to provide an attractive and efficient view of stored contents

Adjustable shelves

Rearrange the refrigerator space to fit any sized item or remove shelves for simple cleanup

Adjustable thermostat

Dial thermostat located inside for easy use

Sealed back

Closed rear offers easier cleanup

Fully finished black cabinet

Allows the unit to be used freestanding

100% CFC free

Environmentally friendly design does not contain ozone-damaging chemicals

CARB Compliant

Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

SUMMIT COMMERCIAL offers a quality selection of beverage centers perfectly designed to maximize impulse sales.

The SCR314L is a compact beverage merchandiser sized for use on top of counters. It is ETL-S listed to NSF-7 standards for commercial applications and meets UL-471. The stainless steel trimmed glass door includes a pro style handle and front lock for added security, while the jet black cabinet suits any setting. The door is user-reversible to accommodate any setup.

Inside, the SCR314L features LED lighting to provide an attractive display when the door is opened. Two adjustable wire shelves offer plenty of storage options, and the white interior finish helps to provide better visibility for stored products. This unit utilizes automatic defrost to reduce user maintenance. The sealed back offers added space savings and easier cleanup.

Perfectly sized and competitively priced, the SCR314L is a great choice for any commercial application in need of a quality beverage center.

BROCHURE w/ DRAWINGS
SCR314L.pdf

TECHNICAL DRAWING (.dwg)
SCR314L_BEVERAGE_CENTER__A-C_2010_.dwg

REVIT MODEL
Qf_Summit_SCR314L_Compact_Beverage_Center.rfa

USE & CARE
SCR489OS_Manual_4-2-2019.pdf

MSDS INFORMATION
R600a_K.pdf

This product can be further customized to specific user requirements. For more information, contact our specialists at 718-893-3900 ext. 220 or info@accucold.com

Due to our commitment to continuous product improvement, all specifications are subject to change without notice.
